Power quality analyzers from YADA Electronics — a Guangdong-based manufacturer (Beijing Stock Exchange: 920556) building online monitoring instruments for industrial networks, data centres and smart infrastructure. This category holds 4 models, headed by the YDPQ200-A at IEC 61000-4-30 Class A with 63rd-order harmonic analysis and 1024 samples per cycle.
Class A Is Not Marketing Language
IEC 61000-4-30 defines two measurement classes. Class S is adequate for surveys and statistical work. Class A specifies the measurement uncertainty, aggregation intervals and time-stamping accuracy required for results to be used in contractual disputes — two Class A instruments measuring the same signal must produce the same answer within defined limits. If the measurement may end up in a discussion with the utility or a supplier, Class A is the only defensible choice.
| Model | Class / Capability | Best Suited To |
|---|---|---|
| YDPQ200-A | IEC 61000-4-30 Class A, 63rd harmonic, 1024 samples/cycle, Class 0.2S active energy | Contractual power-quality monitoring, grid-code compliance evidence, utility disputes. |
| YD6600-N | Three-phase multifunction, RS-485 plus optional Modbus TCP, panel mount | Industrial power systems and smart infrastructure with IP networking already in place. |
| YD2202 | Digital power analyzer, LCD, single and three phase | Industrial, IoT, telecom and smart energy applications. |
| YD6600 Series | Three-phase, RS-485 Modbus RTU | Data-centre power monitoring. |
Power Quality Analyzer Technical Specifications
| Parameter | Specification |
|---|---|
| Compliance class | IEC 61000-4-30 Class A (YDPQ200-A) |
| Harmonic analysis | Up to the 63rd order |
| Sampling | 1024 samples per cycle |
| Active energy accuracy | Class 0.2S |
| Reactive energy accuracy | Class 1.0 |
| Phase configuration | Single-phase and three-phase (YD2202); three-phase (YD6600 series) |
| Communication | RS-485 Modbus RTU; optional Modbus TCP on YD6600-N |
| Monitoring mode | Real-time online |
| Mounting | Panel mount |
Typical Applications
- Grid-code compliance evidence — demonstrating THDi and voltage quality at the point of common coupling.
- Sizing harmonic mitigation — measuring the actual harmonic spectrum before specifying an active filter.
- Data centres — continuous monitoring of UPS rectifier-driven distortion.
- Utility disputes — Class A time-stamped records that stand up in a contractual discussion.
- Industrial troubleshooting — correlating equipment faults with voltage events.
How To Select A Power Quality Analyzer
- Decide whether the result must be defensible. If yes, specify IEC 61000-4-30 Class A.
- Set the harmonic order you need. Six-pulse rectifier loads are dominated by the 5th, 7th, 11th and 13th; high-frequency switching pushes the requirement higher.
- Confirm whether energy accounting is also needed — the YDPQ200-A combines Class 0.2S billing accuracy with the quality measurement.
- Choose the transport. RS-485 Modbus for cabinet-local; Modbus TCP where the site network reaches the panel.
- Confirm panel space and whether the installation is permanent or temporary.
Frequently Asked Questions
What does IEC 61000-4-30 Class A actually guarantee?
It fixes measurement uncertainty, aggregation intervals and time-stamping so that two compliant instruments measuring the same signal agree within defined limits. That reproducibility is what makes the record usable in a contractual dispute.
Why does sampling rate matter?
Resolving harmonics up to the 63rd order requires enough samples per cycle to represent them. The YDPQ200-A takes 1024 samples per cycle, which is what makes high-order analysis meaningful rather than nominal.
Can one instrument do both billing and power quality?
The YDPQ200-A provides Class 0.2S active energy and Class 1.0 reactive energy alongside Class A quality measurement, so a single instrument covers both duties.
Do I need an analyser before buying a harmonic filter?
Yes. Sizing an active filter from nameplate ratings rather than a measured spectrum routinely produces an oversized or undersized unit.
Related Product Categories
- Active Harmonic Filters — the correction equipment sized from these measurements.
- Power Meters — multifunction measurement where full Class A compliance is not required.
- Current Transformers — the sensing elements feeding the analyser.
- AC Energy Meters — energy accounting on the same circuits.
- Surge Protection Devices — transient protection for the monitored board.
Request A Power Quality Analyzer Quote
Send the system voltage, whether the measurement must be IEC 61000-4-30 Class A, the harmonic order required, the CT ratio available and the protocol your monitoring platform expects.
