Product Description
Specification
|
item
|
value
|
|
Place of Origin
|
Guangdong China
|
|
Brand Name
|
YADA
|
|
Model Number
|
DJSF3366
|
|
Display Type
|
Digital Only
|
| Type | DC energy meter |
|
Measuring Energy Range
|
0-999999.99kWh
|
|
Accuracy Class
|
Class B
|
|
Input Voltage
|
DC1000V
|
|
Input Current
|
100(120)A； 200(240)A； 300(360)A； 400(480)A； 500(600)A；
|
|
Operating Temperature
|
-25℃~ 60℃
|
|
Dimensions
|
50.5mm*125.0mm*61.5mm
|
Key Characters
1. Input Voltage: 1000V
2. Input current:
100(120)A~500(600)A
3. LCD Display
4. RS485(Modbus-RTU)
5. With inner diverter
6. CPA Certification(GB/T 33708-2017 Static meter for direct current energy)
Wiring
Directly input
Dimension
Installation
Packing & Delivery
Single packing
Whole box packing
Whole box packing
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
